Dino-lite DermaScope Polarizer HR MEDL7DW

The Dino-Lite DermaScope® Polarizer HR (MEDL7DW) has a 5 megapixel camera to capture sharper images with more detail, and features a built-in and fully adjustable polarization filter to greatly reduce the gloss effect of the skin.

The MEDL7DW has two different levels of magnification (about 20x to about 45x) without the need to change the distance to the skin. If the extra cap is used, it is also possible to take an image with a larger surface area with a magnification of approximately 10x. The MEDL7DW also stands out from the MEDL4DW by the sleek metal casing. The Dino-Lite DermaScope® Polarizer HR is suitable for every dermatologist, but is usually purchased in the practice which places extra demands on the equipment and wants to have the latest features and capabilities.

Specifications

Lighting

• Light/LED Type: White
• Number of LEDs: 8
• LED On/Off Switchable: Yes
• Infrared Filter: IR cut-filter >650 nm
• Diffuser Available: No
• Polarizer: Yes, linear

Optics

• Magnification: 10-50x
• Lens Type: Glass with Anti-Reflection coating

Sensor

• Sensor Type: CMOS
• Resolution: 5 Megapixel (2592x1944)
• Maximum Frame Rate: 30 fps

Compatibility

• Interface: USB 2.0
• Operating Systems: Windows 7, 8, 10 & 11, MacOS 10.9 and up
• Software:
  • Windows: DinoCapture 2.0
  • MacOS: DinoXcope
• Supported Image Formats:
  • Windows: BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
  • MacOS: JPEG, PNG
• Supported Video Formats:
  • Windows: WMV, FLV, SWF
  • MacOS: MOV (max 1.3MP)
• Imaging Standards: DirectShow, UVC

Housing

• Housing Material: Aluminium alloy housing
• Magnification Lock: Yes
• Dimensions: 10.5 cm (L) x 3.2 cm (D)
• Weight: 140 g
• Cable Length: 1.8 m

Features

• Special Feature: No
• Measurement: No
• Calibration: No
• Microtouch Sensor: Yes

Information

• Package Contents: Microscope, carry pouch, software CD, user manual, N3C-C, N3C-D, N3C-E, N3C-L, N3C-S, N3C-D2 caps
• Warranty Information: 2 years European warranty
• Accessory Range: Dino-Lite DermaScope
• Regulatory Approval: Medical Device Class 1 – Medical Devices Regulation (EU) 2017/745
