Moticam Microscopy Camera 4000X
The Moticam 4000X camera boasts on-board software, enabling you to operate it seamlessly with just a mouse and a screen - no computer needed. For added convenience, it offers both USB and Wi-Fi connectivity, allowing for flexible integration with your existing systems. Use the Wi-Fi connectivity to connect effortlessly with mobile devices such as tablets and smartphones, and the USB to connect to a computer for advanced image analysis using the Motic Images Plus software. Experience real-time, live measurements with exceptional clarity and detail, and elevate your microscopy work to new heights.
SPECIFICATIONS |
Model | Moticam 4000X |
Sensor type | CMOS |
Sensor size | 1/2.8" |
Imaging area | 1.45um(H) x 1.45um(V) |
Capture resolution info | 8MP (3840x2160 pixels) |
Image capture resolution (on SD-card) | 8MP (3840x2160 pixels) |
Video capture resolution (on SD-card) | 1080P (1920x1080 pixels) |
Live display mode through USB | 4K (3840x2160 pixels) |
Live display mode through Wi-Fi | 4K (3840x2160 pixels) |
Live display mode through Ethernet | 4K (3840x2160 pixels) |
Live display mode through HDMI | 4K (3840x2160 pixels) |
Pixel size | 1.45x1.45μm |
Scan mode | Progressive |
Shutter mode | Rolling shutter |
Data transfer | HDMI ,USB ,Wi-fi, Ethernet, MicroSD card |
Max. frames per second (fps) | HDMI: 4K (3840x2160) @ 30 fps USB3.0:1920x1080@30fps, 3840X2160@25fps WIFI: 1920x1080@25fps, 3840X2160@12fps |
Exposure time | 0.03ms ~ 1000ms |
Operating temperature | From -10 to +50 Degrees Celsius non condensing |
Sensitivity | 300mV with 1/30s |
Slot | Micro SD Card |
Buttons | ΟN/OFF |
Support device | TWAIN & Direct Show Driver |
Supported OS | Windows 7/8/10, MAC OSX, Linux or higher |
Minimum computer requirements | Core 2, 2,8 GHz, memory RAM 8 GB |
Lens mount | C-Mount |
Focusable lens | 12mm |
Software | On-board Software, Motic Images Plus 3.1 for Windows 10 and MAC OSX or higher and MotiConnect App for iOS and Android |
Functions | Including exposure, gain, white balance, color adjustment, sharpness and denoising control, zoom, mirror, comparison, freeze, measure, cross, browse function |
Power supply | 12V (External Power supply) |
The package includes:
- CS ring adaptor
- focusable lens
- 30mm and 38mm eyepiece adapters
- Motic 4-dot calibration slide
- macro calibration card
- macro tube
- universal power supply
- HDMI cable
- USB 3.0 cable
- Motic Images Plus 3.1
New Moticam 4000X Sneak Peek
Discover the New Moticam 4000X, the ultimate all-round 4K multi-output microscopy camera!
MotiConnect App for computers - First steps
Here's how to get started with our free MotiConnect App for computers. You'll learn how to download and install the app, select your device for the first time, and a general overview of the main tools and features of this fantastic microscopy app.
MotiConnect App for computers - Calibration & Measurements
Wondering how to calibrate and take measurements on the MotiConnect App? Find out how easy it is to start with your investigation by watching this video, and discover how to make annotations and measurements on the great free MotiConnect microscopy App.
Moticonnect App Presentation
Discover Moticonnect, Motic's free microscopy app. Capture, edit and share your microscope images in the blink of an eye.
How to connect your Moticam onto the trinocular tube
Learn how to connect your Moticam onto the trinocular tube easily.
Motic Images Plus 2.0 First Steps
Motic presents another useful tool, the Motic Images Plus 2.0 First Steps presentation. You will learn how to adjust the basic settings, such as the exposure time, white balance and get a faster image, as well as the three ways of capture an image and different scale reference tools.
Motic Images Plus 3.0 - Calibration tutorial
Calibration simply explained: Learn how to calibrate Motic Image Plus 3.0 software, a must in professional environments where exact scale and measurements are a daily need. Easy to follow step-by-step explanation with tips & tricks to perform it accurately. This tutorial is also valid for the 3.1 version of the software.
Motic Images Plus 3.0 - First Steps tutorial
A friendly start: Learn how to make your first steps with Motic Images Plus 3.0 software. From software installation up to making professional measurements, we guide you step by step through getting a great live image, applying image adjustments to see the microscope's image as wished or the most closely to eyepiece observation, and capturing an image or video.
Motic Images Plus 2.0 Calibration Tutorial
Motic presents another useful tool, the Motic Images Plus 2.0 Calibrate and Measure Tutorial. Follow in this video the different steps to calibrate the objectives of your microscope and to check if the calibration is correct. We also give you an overview of the measure options, as well on live images as on the captured images. You can also expect some useful tips, for instance about exporting the measurement information.
Moticams: Let´s talk about them!
Today we will talk about Moticams: what are they, how to use them and how to pimp up standard microscopes!
